DIN Series 10~96W Ultra Slim

MDR-10 MDR-20 MDR-40 MDR-60 MDR-100

Features
• Universal AC input / Full range • Class I, Div 2 Hazardous Locations T4(MDR-40/60)
• Installed on DIN rail TS-35 / 7.5 or 15 • DC OK signal output (MDR-10/20);
• Protections: Short circuit / Overload / Over voltage • DC OK relay contact (MDR-40/60/100)
• No load power consumption <0.75W (<1W for MDR-100) • Cooling by free air convection
• LED indicator for power on • DC output voltage adjustable (MDR-20~100)
• Built-in active PFC and over temp. protection (MDR-100) • 3 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. MDR-10 MDR-20 MDR-40 MDR-60 MDR-100
AC input voltage range 85~264VAC; 120~370VDC
Cold start, 35A at 115VAC, Cold start, 20A at 115VAC, Cold start, 30A at 115VAC,
AC inrush current
70A at 230VAC 40A at 230VAC 60A at 230VAC
DC adjustment range Fixed ±10% rated output voltage 0~+20% rated output voltage
Overload protection >105% hiccup mode, 105%~160% constant current 105%~150% constant current limiting, auto-recovery
auto-recovery
limiting, auto-recovery
Over voltage protection 115%~135% rated output voltage 125%~150% rated output voltage
Setup, rise, hold up time 500ms, 30ms, 120ms 500ms, 30ms, 50ms 3000ms, 50ms, 50ms
Withstand voltage I/P-O/P:3kVAC, I/P-FG:2kVAC, 1minute
Working temperature -20~+70°C (refer to output derating curve) -10~+60°C
DC OK signal Open collector Relay contact

Safety standards UL508, TUV EN62368-1, EAC TP TC 004, BSMI CNS14336-1 approved; MDR-40/60 also approved for UL62368-1,
ANSI/ISA 12.12.01-2013 Class I, Div. 2 Group A, B, C, D Hazardous Locations T4
EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, CNS13438, EN61204-3,
EMC standards
EN61000-6-2 heavy industry level (MDR-40/60/100)
Connection I/P: 3 poles, O/P: 3 poles screw DIN terminal IP: 3 poles, O/P: 6 poles screw DIN terminal
Dimension (WxHxD)(mm) 22.5x90x100 40x90x100 55x90x100
Packing 72pcs / 11.8kg 72pcs / 13.2kg 42pcs / 13.6kg 42pcs / 14.8kg 30pcs / 13.6kg
MDR-10 Series MDR-60 Series
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
MDR-10-5 5V, 0~2.0A ±5% 80mV 77% MDR-60-5 5V, 0~10.0A ±2% 80mV 78%
MDR-10-12 12V, 0~0.84A ±3% 120mV 81% MDR-60-12 12V, 0~5.00A ±1% 120mV 86%
MDR-10-15 15V, 0~0.67A ±3% 120mV 81% MDR-60-24 24V, 0~2.50A ±1% 150mV 88%
MDR-10-24 24V, 0~0.42A ±2% 150mV 84% MDR-60-48 48V, 0~1.25A ±1% 200mV 87%
MDR-20 Series
Model No. Output Tol. R&N Effi. MDR-100 Series
MDR-20-5 5V, 0~3.0A ±2% 80mV 76% Model No. Output Tol. R&N Effi.
MDR-20-12 12V, 0~1.67A ±1% 120mV 80% MDR-100-12 12V, 0~7.5A ±1% 120mV 83%
MDR-20-15 15V, 0~1.34A ±1% 120mV 81% MDR-100-24 24V, 0~4.0A ±1% 150mV 86%
MDR-20-24 24V, 0~1.00A ±1% 150mV 84% MDR-100-48 48V, 0~2.0A ±1% 200mV 87%
MDR-40 Series
Energy Saving —
Model No. Output Tol. R&N Effi. We care about energy saving. This logo represents
MDR-40-5 5V, 0~6.00A ±2% 80mV 78% that this model has "low no load power consumption"!
MDR-40-12 12V, 0~3.33A ±1% 120mV 86%
MDR-40-24 24V, 0~1.70A ±1% 150mV 88% To satisfy our customers is our goal —
• High Quality

• Low Cost
MDR-40-48 48V, 0~0.83A ±1% 200mV 88% • Prompt Delivery • Best Service
