DIN Series 15~60W Ultra-slim Step Shape
Features
• Isolation Class II
NE
W • Universal AC input / Full range (277VAC operational)
• No load power consumption<0.3W
• Compact size with 1SU~4SU width
• Class 2 power unit / Pass LPS
• Protections: Short circuit / Overload / Over voltage
• Can be installed on DIN rail TS-35 / 7.5 or 15
• Cooling by free air convection
• DC output voltage adjustable
• LED indicator for power on
HDR-15 HDR-30 HDR-60 • Suitable for building automation and control of
household appliance
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. HDR-15 HDR-30 HDR-60
AC input voltage range 85~264VAC (277VAC operational); 120~370VDC (390VDC operational)
AC inrush current (max.) Cold start, 45A at 230VAC Cold start, 60A at 230VAC
DC adjustment range 5V: 4.5~5.5V, 12V: 10.8~13.8V, 15V: 13.5~18V, 24V: 21.6~29V, 48V: 43.2~55.2V
Overload Range 110%~145% 105%~160%
protection Type constant current limiting, auto-recovery
Over voltage Range 115%~150% rated output voltage
protection Type Shut off, clamp by zener diode Shut down, re-power on to recover
Withstand voltage I/P-O/P: 4kVAC
Working temperature -30~+70°C (refer to output load derating curve)
Vibration 10~500Hz, 2G 10 min./1 cycle, period for 60 min. each along X, Y, Z axes
Safety standards UL62368-1, UL508, TUV EN61558-2-16, IEC62368-1, EAC TP TC 040, BSMI CNS14336-1 approved
EMC standards EN55032 class B, EN61000-3-2,3, EN61000-6-2, EN61000-4-2,3,4,5,6,8,11, EN61204-3
Connection I/P and O/P:2 poles screw DIN terminal I/P: 2 poles, O/P: 4 poles screw DIN terminal
Dimension (WxHxD)(mm) 17.5x 90x 54.5 35x 90x 54.5 52.5x 90x 54.5
Packing 160pcs / 13.5kg 96pcs / 12.5kg 60pcs / 12.4kg
15W HDR-15 60W HDR-60
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
HDR-15-5 5V, 0~2.40A ±2% 80mV 80% HDR-60-5 5V, 0~6.5A ±2% 80mV 85%
HDR-15-12 12V, 0~1.25A ±1% 120mV 85% HDR-60-12 12V, 0~4.5A ±1% 120mV 88%
HDR-15-15 15V, 0~1.00A ±1% 120mV 85.5% HDR-60-15 15V, 0~4.0A ±1% 120mV 89%
HDR-15-24 24V, 0~0.63A ±1% 150mV 86% HDR-60-24 24V, 0~2.5A ±1% 150mV 90%
HDR-15-48 48V, 0~0.32A ±1% 240mV 87% HDR-60-48 48V, 0~1.25A ±1% 240mV 91%
30W HDR-30
Model No. Output Tol. R&N Effi.
