Page 27 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG
P. 27
DIN Series 92~150W Ultra-slim Step Shape
Features
• Isolation Class II
• Universal AC input / Full range (277VAC operational)
• No load power consumption<0.3W
• Compact size with 4SU~6SU width
• Class 2 power unit / Pass LPS (HDR-100 only)
• Over voltage category III
• Protections: Short circuit / Overload / Over voltage
• Can be installed on DIN rail TS-35 / 7.5 or 15
• Cooling by free air convection
• DC output voltage adjustable
• LED indicator for power on
• Suitable for building automation and control of
HDR-100 HDR-150
household appliance
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. HDR-100□ HDR-150
AC input voltage range 85~264VAC (277VAC operational); 120~370VDC (390VDC operational)
AC inrush current (max.) Cold start, 70A at 230VAC
HDR-100
12V: 12~13V, 15V: 15~17V, 12V: 10.8~13.8V
24V: 24~25.5V, 48V: 48~48.7V 15V: 13.8~18V
DC adjustment range
HDR-100-N 24V: 21.6~29V
12V: 12~13.8V, 15V: 13.8~18V, 48V: 43.2~55.2V
24V: 21.6~29V, 48V: 43.2~55.2V
HDR-100: 102%~110%;
Overload Range HDR-100-xxN: 105%~150% 105%~180%
protection
Type constant current limiting, auto-recovery
Over voltage Range 125%~155% rated output voltage
protection Type Shut down, re-power on to recover
Withstand voltage I/P-O/P: 3kVAC
Working temperature -30~+70°C (refer to output load derating curve)
Vibration 10~500Hz, 2G 10 min./1 cycle, period for 60 min. each along X, Y, Z axes
Safety standards UL62368-1, UL508, TUV EN61558-2-16, IEC62368-1, BSMI CNS14336, AS/NZS60950.1 approved
EMC standards EN55032 class B, EN61000-3-2,3, EN61000-6-2, EN61000-4-2,3,4,5,6,8,11, CNS13438, EN61204-3
Connection I/P: 2 poles, O/P: 4 poles screw DIN terminal
Dimension (WxHxD)(mm) 70x 90x 54.5 105x 90x 54.5
Packing 48pcs / 14kg
100W HDR-100 150W NEW HDR-150
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
HDR-100-12 12V, 0~7.1A ±2% 120mV 88%
HDR-150-12 12V, 0~12.5A ±2% 120mV 88%
HDR-100-12N 12V, 0~7.5A ±2% 120mV 88%
HDR-100-15 15V, 0~6.13A ±1% 120mV 89% HDR-150-15 15V, 0~10A ±1% 120mV 89%
HDR-100-15N 15V, 0~6.5A ±1% 120mV 89%
HDR-150-24 24V, 0~6.25A ±1% 150mV 90%
HDR-100-24 24V, 0~3.83A ±1% 150mV 90%
HDR-100-24N 24V, 0~4.2A ±1% 150mV 90%
HDR-150-48 48V, 0~3.2A ±1% 240mV 90%
HDR-100-48 48V, 0~1.92A ±1% 240mV 90%
HDR-100-48N 48V, 0~2.1A ±1% 240mV 90%
HDR-100: 92W max., pass LPS
HDR-100-xxN: 100W max., non-LPS with a wide output adjustable range
