Page 92 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Security Series 40~100W Single Output

Features
• Single output with battery charger
(UPS function)
• Universal AC input / Full range
• Can be installed on DIN rail
TS-35/7.5 or 15
• Protections:
Short circuit / Overload / Over voltage /
Battery low protection / Battery reverse
polarity protection by fuse
• Alarm signal for AC OK and battery low
• Cooling by free air convection
• Pass LPS (DRC-40/60)
• LED indicator for power on
DRC-40 DRC-60 DRC-100
• 100% full load burn-in test
• 3 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.)

Model No. DRC-40 DRC-60 DRC-100
AC input voltage range 90~264VAC; 127~370VDC
AC inrush current (max.) Cold start, 30A at 115VAC, 60A at 230VAC
DC adjustment range CH1,13.8V: 12~15V; 27.6V:24~30V
Overload protection 105%~150% hiccup mode, auto-recovery
Over voltage protection 105%~135% rated output voltage
Setup, rise, hold up time 400ms, 50ms, 50ms at full load and 230VAC 2400ms, 50ms, 50ms at full load and 230VAC
Withstand voltage I/P-O/P:3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature -30~+70°C (refer to output derating curve)
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004 approved
EMC standards EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EAC TP TC 020
Connection (screw DIN terminal) I/P:3 poles, O/P: 8 poles I/P:3 poles, O/P: 10 poles
Case No. 962A 973A
Dimension (LxWxH)(mm) 40x 90x 100 55x 90x 100

40W DRC-40 100W DRC-100
Model No. Output Tol. R&N Effi. Max. Model No. Output Tol. R&N Effi. Max.
DRC-40A 13.8V, 0~2.9A ±1% 120mV 86% 40W DRC-100A 13.8V, 0~7A ±1% 120mV 87% 97W
13.8V, 0~1.0A (Charger) 13.8V, 0~2.5A (Charger)
DRC-40B 27.6V, 0~1.45A ±1% 200mV 87% 40W DRC-100B 27.6V, 0~3.5A ±1% 240mV 89% 97W

27.6V, 0~0.5A (Charger) 27.6V, 0~1.25A (Charger)
60W DRC-60
Model No. Output Tol. R&N Effi. Max.
DRC-60A 13.8V, 0~4.3A ±1% 120mV 86% 59W
13.8V, 0~1.5A (Charger)

DRC-60B 27.6V, 0~2.15A ±1% 200mV 88% 59W
