Page 44 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Green Open Frame 300~400W Single Output Medical Grade

RPS-400-TF RPS-400-SF

Airflow
direction 160
86
23.5 Airflo w
direction
43
43
RPS-300 RPS-400 86 130 45.6 130
(5"x3") (5"x3")

RPS-300-x-C RPS-400-x-C RPS-400-x-TF RPS-400-x-SF

Features
• Universal AC input / Full range • Extremely low leakage current
• Built-in active PFC function • Built-in P.G, P.F signal output and remote sense function
• Medical safety approved (2xMOPP) • No load power consumption <0.5W
• Suitable for BF application with appropriate system consideration • Built-in 12V/0.5A fan supply
• Class I or Class II configuration • Standby 5V@1A
• Protections: • LED indicator for power on
Short circuit / Overload / Over voltage / Over temperature • 3 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. RPS-300-x RPS-400-x

Rated Fan 300W (20.5CFM) 400W (25CFM)
Power Convection 200W 250W
AC input voltage range 90~264VAC 80~264VAC
Leakage current PCB type: <140μA; Enclosed type: <200μA <160μA
DC adjustment range ±5%
Overload protection 105%~135% hiccup mode, auto-recovery
Withstand voltage I/P-O/P: 4kVAC, I/P-FG:2kVAC, O/P-FG: 1.5kVAC
Working temperature -30~+70°C (refer to output derating curve)
Safety standards ANSI/AAMI ES60601-1, TUV EN60601-1, EAC TP TC 004 approved
EMC standards EN55011 class B (Radiation class A), EN61000-3-2,-3; EN60601-1-2, EAC TP TC 020
Connection JST B5P / screw terminal
PCB : 127x 76.2x 35 (5"x3") PCB : 127x 76.2x 35 (5"x3")
Dimension (LxWxH)(mm) Case: 130x 86x 43 Case: 130x 86x 43(-C); 130x 86x 66.5(-TF); 160x 86x 43(-SF)
300W—Class I or II RPS-300 400W—Class I or II RPS-400

Model No. Output (Convection / 20.5CFM) Tol. R&N Effi. Model No. Output (Convection/25CFM) Tol. R&N Effi.
RPS-300-12□ 12V, 16.67A / 25A ±3% 120mV 90.0% RPS-400-12□ 12V, 20.8A / 33.3A ±3% 120mV 91.5%
RPS-400-15□
RPS-300-15□ 15V, 13.33A / 20A ±3% 120mV 90.0% RPS-400-18□ 15V, 16.7A / 26.7A ±3% 120mV 92%
18V, 13.9A / 22.3A
±3%
150mV
93%
RPS-300-24□ 24V, 8.33A / 12.5A ±2% 150mV 92.5% RPS-400-24□ 24V, 10.5A / 16.7A ±2% 150mV 93%
RPS-400-27□
RPS-300-27□ 27V, 7.4A / 11.12A ±2% 200mV 93.0% RPS-400-36□ 27V, 9.3A / 14.9A ±1% 200mV 93.5%
94%
±1%
200mV
36V, 7A / 11.2A
RPS-300-48□ 48V, 4.17A / 6.25A ±2% 200mV 93.0% RPS-400-48□ 48V, 5.3A / 8.4A ±1% 200mV 94%
= blank, -C, -TF, -SF:
blank: PCB type, -C: Enclosed type, -TF: Enclosed type with fan on the top,
□= blank, -C; blank: PCB type, -C: Enclosed type -SF: Enclosed type with fan on the side
41
