Page 20 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Enclosed-PFC 100~300W High Reliability Medical Grade

Features
• Universal AC input / Full range
• Medical safety approved (2xMOOP)
• Withstand 300VAC surge input for 5 seconds
• Built-in active PFC function
• Protections: Short circuit / Overload / Over voltage /
Over temperature
• 1U low profile
• Built-in constant current limiting circuit
• Built-in remote sense function (MSP-200/300)
• No load power consumption <0.5W
• Built-in remote ON/OFF control
• Built-in 5V/0.3A standby output (MSP-200/300)

MSP-300 MSP-200 MSP-100 • Built-in DC OK signal (MSP-300)
• LED indicator for power on
• 5 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. MSP-100 MSP-200 MSP-300
AC input voltage range 85~264VAC; 120~370VDC
Leakage current <300μA <450μA
AC inrush current (max.) Cold start, 65A at 230VAC Cold start, 70A at 230VAC
DC adjustment range ±15% rated output voltage
Overload Range 105%~135%
protection Type Constant current limiting, auto-recovery
Over voltage protection 115%~145%
Withstand voltage I/P-O/P: 4kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC, 1 minute
Working temperature -40~+60°C -40~+70°C (refer to output derating curve)
Safety standards ANSI/AAMI ES60601-1, IEC60601-1, EAC TP TC 004 approved
EMC standards EN55011 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EN60601-1-2, EAC TP TC 020
Connection 7P / 9.5mm pitch terminal block with cover 7P / 11mm pitch
terminal block with cover
Dimension (LxWxH)(mm) 159x 97x 38 199x 98x 38 199x 105x 41
Case No. 901I 902E 980A

100W MSP-100 Model No. Output Tol. R&N Effi.

Model No. Output Tol. R&N Effi. MSP-200-12 12V, 0~16.7A ±1% 120mV 88.0%
MSP-100-3.3 3.3V, 0~20A +2.5%, -3.5% 80mV 78.0% MSP-200-15 15V, 0~13.4A ±1% 150mV 88.0%
MSP-100-5 5V, 0~17A +2.5%, -3.5% 80mV 83.0% MSP-200-24 24V, 0~8.4A ±1% 150mV 88.0%
MSP-100-7.5 7.5V, 0~13.5A ±2.5% 100mV 84.0% MSP-200-36 36V, 0~5.7A ±1% 250mV 89.0%
MSP-100-12 12V, 0~8.5A ±1.5% 120mV 87.5% MSP-200-48 48V, 0~4.3A ±1% 250mV 89.0%
MSP-100-15 15V, 0~7A ±1.5% 150mV 88.0%
300W MSP-300
MSP-100-24 24V, 0~4.5A ±1.5% 150mV 88.5%
Model No. Output Tol. R&N Effi.
MSP-100-36 36V, 0~2.9A ±1.5% 200mV 89.0%
MSP-300-3.3 3.3V, 0~60A ±2.5% 80mV 80.0%
MSP-100-48 48V, 0~2.2A ±1.5% 240mV 90.0%
MSP-300-5 5V, 0~60A ±2% 90mV 82.0%
MSP-300-7.5 7.5V, 0~40A ±2% 100mV 86.0%
200W MSP-200 MSP-300-12 12V, 0~27A ±1% 120mV 88.0%

Model No. Output Tol. R&N Effi. MSP-300-15 15V, 0~22A ±1% 150mV 88.0%
MSP-200-3.3 3.3V, 0~40A ±2% 80mV 80.0% MSP-300-24 24V, 0~14A ±1% 150mV 87.0%
MSP-200-5 5V, 0~35A ±2% 90mV 84.0% MSP-300-36 36V, 0~9A ±1% 250mV 88.0%
MSP-200-7.5 7.5V, 0~26.7A ±2% 100mV 86.0% MSP-300-48 48V, 0~7A ±1% 250mV 89.0%

17
