Enclosed-PFC 5000~10000W Programmable High Power
RST-5000 RST-10000
Features
• 3 3-wire/ 196~305VAC or 3 4-wire/ Y 340~530VAC wide input range • Built-in current sharing up to 20kW
• Built-in active PFC function (4 units of RST-5000 or 2 units of RST-10000)
• High efficiency up to 91% • Built-in remote sense and ON/OFF control
• Protections: • Built-in 12V/0.1A auxiliary power
Short circuit / Overload / Over voltage / Over temperature / Fan alarm • Alarm signal output
• Forced air cooling by built-in DC fan • 5 years warranty
• Output voltage and constant current level Icc programmable
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. RST-5000 RST-10000
AC input voltage range 3 3-wire/ 196~305VAC or 3 4-wire/ Y 340~530VAC
Cold start, 75A at 230VAC (3 3-wire/ ) Cold start, 150A at 230VAC (3 3-wire/ )
AC inrush current (max.)
or 50A at 400VAC (3 4-wire/ Y) or 100A at 400VAC (3 4-wire/ Y)
Vo: -2%~+20% by potentiometer or to 20%~120% of rated output voltage by 1~6VDC external control signal
DC adjustment range
Icc: to 20%~100% of rated output current by 1~5VDC external control signal
Range 100%~112%
Overload
protection Type User adjustable continuous constant current limiting or constant current limiting with delay shutdown after 5 seconds.
Re-power on to recover.
Over voltage Range 125%~140%
protection Type Shut down O/P voltage, re-power on to recover
Withstand voltage I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature -30~+70°C (refer to output derating curve)
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004 approved
EMC standards EN55032 class A, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2, EN61204-3
Input 6P/13mm pitch terminal block with cover
Connection
Output Bus bars
Dimension (LxWxH) (mm) 460x 211x 83.5 540x 424x 83.5
Case No. 223A 234A
Packing 10kg; 1pcs / 10.1kg / 1.15CUFT 23.5kg; 1pcs / 23.5kg / 2.45CUFT
5000W RST-5000 10000W RST-10000
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
RST-5000-24 24V, 0~200A ±1% 150mV 89% RST-10000-24 24V, 0~400A ±1% 150mV 89%
RST-5000-36 36V, 0~138A ±1% 200mV 90% RST-10000-36 36V, 0~276A ±1% 200mV 90%
RST-5000-48 48V, 0~105A ±1% 200mV 91% RST-10000-48 48V, 0~210A ±1% 200mV 91%
