Page 16 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Enclosed-PFC 750~2000W Programmable High Power

Features
• 1U low profile (41mm)
• Universal AC input / Full range
• Built-in active PFC function
• Protections: Short circuit / Overload / Over voltage /
Over temperature
• Forced air cooling by built-in DC fan
• High power density up to 25W/in³ (RSP-1600)
• Output voltage programmable
Constant current level Icc programmable (RSP-750/1600)
• Built-in current sharing up to 4 units (RSP-1000/2000)
or 6 units (RSP-1600)
• Built-in remote sense and ON/OFF control
• Built-in auxiliary power, DC OK signal
• OTP alarm signal output (RSP-1600/2000)
RSP-2000 RSP-1600 RSP-1000 RSP-750 • Optional conformal coating
• 5 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.) (except for RSP-750)
Model No. RSP-750 RSP-1000 RSP-1600 RSP-2000

AC input voltage range 90~264VAC; 127~370VDC 90~264VAC; 127~320VDC
AC inrush current (max.) Cold start, 40A at 230VAC Cold start, 35A at 230VAC Cold start, 50A at 230VAC
Vo: ±10% by potentiometer, Vo: ±10% by potentiometer, Vo: -1%~+22.5% by Vo: ±10% by potentiometer, or
or to 40%~110% of rated or to 40%~110% of rated potentiometer, or to 40%~ to 40%~115% of rated
output voltage by output voltage by 125% of rated output output voltage by
2~5.5VDC external external resistor or by voltage by 1~5VDC 1~4.7VDC external control
DC adjustment range control signal 2~5.5VDC external external control signal signal
Icc : to 40%~110% of rated control signal Icc: to 20%~100% of rated
output current by output current by 1~5VDC
2~5.5VDC external external control signal
control signal
Range 105%~125% 105%~125% 105%~115% 105%~125%
Overload
protection Type Constant current limiting, auto-recovery Constant current limiting, shut down o/p voltage after 5 sec.
, re-power on to recover
Over voltage Range 115%~145% 115%~135% 130%~155% 120%~145%
protection Type Shut down O/P voltage, re-power on to recover
Withstand voltage I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC (O/P-FG: 1.5kVAC for RSP-1600)
Working temperature -30~+70°C -20~+60°C -30~+70°C -35~+70°C
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004, BSMI CNS14336-1 approved
EMC standards EN55032 class B for RSP-750, class A for RSP-1000/1600/2000; EN61000-3-2,3; EN61000-4-2,3,4,5,6,8,11, EN61204-3
Input 3P / 10mm pitch terminal block with cover
Connection
Output M5x12 screw terminal Bus bars M5x12 screw terminal
Dimension (LxWxH) (mm) 250x127x41 295x 127x 41 300x 85x 41 295x 127x 41
Case No. 212A 952B 237B 952D

750W RSP-750 1600W RSP-1600
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
RSP-750-5 5V, 0~100A ±2% 150mV 82.0% RSP-1600-12 12V, 0~125A ±1% 150mV 89.0%
RSP-750-12 12V, 0~62.5A ±1% 150mV 87.0% RSP-1600-24 24V, 0~67A ±1% 200mV 91.5%
RSP-750-15 15V, 0~50A ±1% 150mV 89.0% RSP-1600-27 27V, 0~59A ±1% 200mV 92.0%
RSP-750-24 24V, 0~31.3A ±1% 150mV 90.5%
RSP-750-27 27V, 0~27.8A ±1% 150mV 90.5% RSP-1600-36 36V, 0~44.5A ±1% 250mV 92.0%
RSP-750-48 48V, 0~15.7A ±1% 150mV 92.0% RSP-1600-48 48V, 0~33.5A ±1% 300mV 93.0%
1000W RSP-1000 2000W RSP-2000
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
RSP-1000-12 12V, 0~60A ±1% 150mV 83%
RSP-1000-15 15V, 0~50A ±1% 150mV 85% RSP-2000-12 12V, 0~100A ±2% 150mV 87.0%
RSP-1000-24 24V, 0~40A ±1% 150mV 88% RSP-2000-24 24V, 0~80A ±1% 200mV 90.5%
RSP-1000-27 27V, 0~37A ±1% 150mV 88%
RSP-1000-48 48V, 0~21A ±1% 150mV 90% RSP-2000-48 48V, 0~42A ±1% 300mV 92.0%
