Page 63 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Industrial Adaptor 29~50W Triple Output Desktop Type

GP25A GP25B GP50A

Features
• Universal AC input / Full range • Class I power unit (with earth pin) for A type;
• No load power consumption <0.3W • Class II power unit (without earth pin) for B type
• Energy efficiency Level VI • Fully enclosed plastic case
• Protections: • LED indicator for power on
Short circuit / Overload / Over voltage / Over temp. (GP25) • Dual output available (optional)
• Comply with EISA 2007/DoE, EU ErP • 3 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.)

Model No. GP25A GP25B GP50A

AC input voltage range 90~264VAC ; 135~370VDC
AC inrush current (max.) Cold start, 60A at 230VAC Cold start, 45A at 230VAC
Overload protection Hiccup mode, auto recovery

Over voltage protection 110%~140% of +5V output
Setup, rise, hold up time 800ms, 50ms, 20ms 1000ms, 50ms, 20ms
Withstand voltage I/P-O/P:3kVAC, I/P-FG:1.5kVAC , 1 minute

Working temperature -20~+70°C (refer to output derating curve)
Safety standards UL62368-1, CSA22.2, TUV EN62368-1, EAC TP TC 004 approved
EMC standards EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,11, FCC part15 class B

Length of output cable 150cm of UL2464 100cm of UL2464
Standard DC Plug
(refer to page 59 for DC plug) R1B: DIN 5P
Dimension (LxWxH)(mm) 107.5x 67x 36 146x 75.5x 43

29W GP25A/B Series 50W GP50A Series

Order No. Output Tol. R&N Effi. Max. Order No. Output Tol. R&N Effi. Max.
GP25□13A-R1B 5V, 0.5~2.5A ±5% 50mV 80.0% 28.5W GP50A13A-R1B 5V, 0.0~4.0A ±5% 50mV 84.0% 46.5W
12V, 0.2~1.2A -5%~+10% 100mV
12V, 0.3~2.0A ±3% 100mV
-5V, 0.1~0.3A ±3% 50mV
-5V, 0.1~0.5A -5%~+10% 100mV
GP25□13D-R1B 5V, 0.5~2.5A ±5% 60mV 80.0% 28W
GP50A13D-R1B 5V, 0.0~4.0A ±5% 50mV 84.0% 50W
12V, 0.2~1.0A ±5% 120mV
12V, 0.3~2.0A ±3% 150mV
-12V, 0.1~0.3A ±3% 50mV
-12V, 0.1~0.5A -5%~+8% 100mV
GP25□14E-R1B 5V, 0.5~2.5A ±5% 100mV 80.5% 29W
15V, 0.1~0.8A -5%~+15% 150mV GP50A14E-R1B 5V, 0.0~4.0A ±5% 50mV 84.5% 50W
-15V, 0.1~0.3A ±3% 50mV 15V, 0.3~1.5A ±3% 150mV
□= A / B; A: IEC 320-C14 / Class I ,B: IEC 320-C8 / Class II -15V, 0.1~0.5A -5%~+15% 150mV

60
