Page 69 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Moistureproof Adaptor 60~120W Single Output

Features
• IP67 design for power body
• Universal AC input / Full range (except for OWA-120E)
AC input 180~264VAC only (OWA-120E)
• No load power consumption <0.15W
• Energy efficiency Level VI
• E-Type: meet CoC Version 5 (OWA-60E/90E);
comply with EU ErP
U-Type: Comply with EISA 2007/DoE and NRCan
• Built-in active PFC function (OWA-90/120)
• Class II power (without earth pin)
OWA-60E/U OWA-90E/U OWA-120E/U • Fanless design, cooling by free air convection
E-Type U-Type • Fully enclosed plastic case
• Protections: Short circuit / Over current /
AC Input Plug Over voltage / Over temperature
• Suitable for household appliances or the electronic
DC Output Plug OWA-60E OWA-90E/120E OWA-60U OWA-90U/120U applications at highly dusty or damp environment
• 5 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. OWA-60 OWA-90 OWA-120
AC input voltage range 90~264VAC; 127~370VDC (180~264VAC ; 254~370VDC for OWA-120E)
AC inrush current (max.) Cold start, 65A at 230VAC Cold start, 60A at 230VAC
Overload protection E-Type: 105~115% hiccup mode, auto-recovery; U-Type: 95~108% constant current limiting, auto-recovery
Over voltage protection 110%~140% rated output voltage, re-power on to recover
Over temperature protection Shut down output voltage, re-power on to recover
Withstand voltage I/P-O/P: 3.75KVAC
Working temperature -35~+70°C -40~+70°C (refer to output derating curve)
E-Type: DEKRA EN60335-1(except for 48~54V), E-Type: DEKRA EN60335-1(except for 42~54V), E-Type: DEKRA EN60335-1(except for 48~54V),
Safety standards EN61558-1, EN61558-2-16 approved; EN61558-1, EN61558-2-16 approved; EN61558-1, EN61558-2-16 approved;
U-Type: UL8750 listed approved, EAC TP TC 004 U-Type: UL8750 listed approved, EAC TP TC 004 U-Type: UL8750 listed approved, EAC TP TC 004
EMC standards E-Type: EN55032 class B, EN55014, EN61000-3-2,-3; U-Type: FCC Part 15, EAC TP TC 020
Input E-Type: CEE 7/7 EU plug; U-Type: NEMA 1-15P plug
Standard E-Type: XLR 4P, male type;
plug Output 2.1øx5.5øx11mm / C+, tuning fork type U-Type: P1M, 2.5øx5.5øx11mm / C+, tuning fork type (OWA-90U 20~54V only) or
R7B, Power DIN 4P with lock type
Input E-Type: 150cm of H05RN-F 1.0mm x2C; U-Type: 150cm of SVT 18AWGx2C
2
Length of 2 E-Type: 30cm of H05RN-F 1.0mm x2C 2
2
cable Output E-Type: 30cm of H05RN-F 1.0mm x2C U-Type: 30cm of UL2464 18AWG x4C for R7B; E-Type: 30cm of H07RN-F 1.5mm x2C
U-Type: 30cm of UL1185 16AWG x2C U-Type: 30cm of UL2464 18AWG x4C
30cm of UL2464 16AWGx2C for P1M
Dimension (LxWxH)(mm) 130x 53x 35 171x 63x 37.5 191x 63x 37.5
□
OWA-60 Series OWA-90 -30- 30V, 0~3A ±3.0% 200mV 90%
□
(E-Type) (U-Type, 42~54V) (U-Type, 12~36V) (E-Type) (E-Type) (U-Type) OWA-90 -36- 36V, 0~2.5A ±2.0% 200mV 91%
□
Model No. Output Tol. R&N Effi. OWA-90 -42- 42V, 0~2.15A ±1.0% 250mV 91%
□
□
OWA-60 -12 12V, 0~5A ±4.0% 150mV 88% OWA-90 -48- 48V, 0~1.88A ±1.0% 250mV 91%
□
□
OWA-60 -15 15V, 0~4A ±4.0% 150mV 89% OWA-90 -54- 54V, 0~1.67A ±1.0% 350mV 91%
□
OWA-60 -20 20V, 0~3A ±4.0% 150mV 89% □
= E / U ; E: European 2P, U: American 2P ; =Blank(R7B)/P1M
□
OWA-60 -24 24V, 0~2.5A ±3.0% 150mV 90%
□
OWA-60 -30 30V, 0~2A ±3.0% 200mV 90% OWA-120 Series (E-Type) (U-Type) (E-Type) (E-Type) (U-Type)
□
OWA-60 -36 36V, 0~1.67A ±2.0% 200mV 90% Model No. Output Tol. R&N Effi.
□
OWA-60 -42 42V, 0~1.5A ±1.0% 250mV 90% OWA-120E-12 12V, 0~9.6A ±4.0% 150mV 87.5%
□
OWA-60 -48 48V, 0~1.25A ±1.0% 250mV 91% OWA-120U-12 12V, 0~10A ±4.0% 150mV 87.5%
□
OWA-60 -54 54V, 0~1.12A ±1.0% 350mV 91% □
□ OWA-120 -15 15V, 0~8A ±4.0% 150mV 89.0%
□
= E / U ; E: European 2P, U: American 2P
OWA-120 -20 20V, 0~6A ±4.0% 150mV 90.0%
□
OWA-90 Series OWA-120 -24 24V, 0~5A ±4.0% 150mV 90.5%
□
(E-Type) (U-Type, 42~54V) (U-Type, 12~36V) (E-Type) (U-Type) OWA-120 -30 30V, 0~4A ±3.0% 200mV 90.0%
□
Model No. Output Tol. R&N Effi. OWA-120 -36 36V, 0~3.4A ±2.0% 200mV 90.0%
□
□
OWA-90 -12 12V, 0~7.5A ±4.0% 150mV 89% OWA-120 -42 42V, 0~2.9A ±1.0% 250mV 90.5%
□
□
OWA-90 -15 15V, 0~6A ±4.0% 150mV 90% OWA-120 -48 48V, 0~2.5A ±1.0% 250mV 90.5%
□
□
OWA-90 -20- 20V, 0~4.5A ±4.0% 150mV 90% OWA-120 -54 54V, 0~2.3A ±1.0% 350mV 90.5%
□
= E / U ; E: European 2P, U: American 2P
OWA-90 -24- 24V, 0~3.75A ±3.0% 150mV 90% □
66
