Page 73 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Charger Smart Battery Charging Programmer

Features
• For MEAN WELL's intelligent battery chargers with
NE
W
charging curve programmable function (ENC/RPB/RCB series)
• Simple connection and configuration
• No need of battery or AC power
• LED status indicator
SBP-001

General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. SBP-001
Programming interface PMBus, CANBus, UART
LED indicator Green: 3.3V interface Orange: 5V interface
Programming volt. 5V and 3.3V, for programming purpose only. Total 0.5W(max.)
Comm. interface USB
Working temperature 0~ +40 C
o
Dimension (LxWxH)(mm) 165x 46x 23
Description
The Smart Battery Charging Programmer Software is utilized for programming MEAN WELL's intelligent chargers, including ENC, RPB and RCB
series. The connection between personal computer (PC) and charger is established via the “programmer” hardware interface from MEAN WELL.
What function is provided?
Charging parameter adjustment: Values of constant current (CC), constant voltage (CV), float voltage (FV) and tapper current (TC) can be set
and adjusted.
Battery temperature compensation: Various charging voltage compensation is provided for battery at different temperature conditions.
Timeout setting: Fully programmable timeout during stages enables to be set to shutdown the charger to prevent battery over-charge.
Hardware Connection
Prior to program a driver, the connection between driver and PC must be established first via the Programmer shown in the figure below. The
following steps are suggested:
ENC series with SBP-001:
1.Remove the ENC from AC.
2.Connect Programmer and PC with the enclosed USB cable. LED (GREEN) of the Programmer is ON.
3.Connect the communication cable to CN31 of the ENC from the Programmer.
RPB/RCB series with SBP-001:
1.Remove the RPB/RCB from AC.
2.Connect Programmer and PC with the enclosed USB cable. LED (GREEN) of the Programmer is ON.
3.Connect the communication cable to CN1 and CN500 of the RPB from the Programmer; RCB requires working with a RHP rack,
link the cable to JK1 of the rack.
4. Apply AC to the charger.
5. LED of the Programmer will light in ORANGE once connection is established successfully.

ENC
To the personal
computer USB port
(Type A)

CN31
USB
Personal Computer

RPB CN500 To the
programmer
(Mini USB)

CN1

RHP rack with RCB

JK1
