Page 71 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Charger 120~230W Portable Battery Charger

Power Factor
Correction Choke Output Diode
of Charger

2 Color LED
Indicator

115 / 230 Selectable Fan Connector Fast Charging Circuit
(A/B Selectable)
PA/PB-120 PA/PB-120 (PCB type) PB-230
Features for PA/PB-120 PA/PB-120 (PCB type) Features for PB-230
• Stationary charger for lead-acid batteries • Stationary charger for lead-acid batteries and Li-ion batteries
• AC input range selectable by switch
• Charging type selectable (optional) • Universal AC input/Full range
• Passive PFC option • 3 stage charging
• Protections: • Built-in active PFC function
Short circuit / Overload / Over voltage / Over temp. • Protections: Short circuit / Overload / Over voltage / Over temp.
• Built-in ON/OFF power switch • Built-in remote ON/OFF control
• 3 poles AC inlet with fuse holder • Fan ON/OFF control
• 2 color LED loading indicator
• Open frame models available (without safety approvals) • 2 color LED loading indicator
• 2 years warranty • 2 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Model No. PA/B-120 PB-230
AC input voltage range 88~132VAC/ 176~264VAC selectable by switch 90~264VAC; 127~370VDC
AC inrush current (max.) Cold start, 50A at 230VAC
Overload protection 90%~110% constant current limiting ,auto-recovery
Over voltage protection 108%~127% hiccup mode, auto-recovery 102%~125% shut down o/p voltage, auto-recovery
Setup, rise, hold up time 1000ms, 50ms, 16ms at full load and 230VAC NA
Withstand voltage I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature -10~+45°C (refer to output derating curve) -20~+50°C (refer to output derating curve)
UL62368-1, TUV EN62368-1, EN60335-1, EAC TP TC 004, UL1012, EAC TP TC 004 (PB-230xx-AD1 only),
Safety standards
EN60335-2-29(except for 55.2V) approved TUV EN60950-1, PSE J60950-1 approved
EMC standards EN55032 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EAC TP TC 020 EN55032 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EAC TPTC020
Dimension (LxWxH)(mm) Case Type: 180x 96x 49; PCB Type: 144x 90x 33 190x 96x 49
Order Information for PA/PB-120 Order Information for PB-230

PA -120P-xx PB-230-xx

A: Voltage detector P: Open PCB
B: Current detector C: With case Blank: XLR 4P (standard)
AD1: Anderson connector (optional)

Charging Curve for PA/PB-120

PA/B-120 Series PB-230 Series Prod uct Safety P S E
TUV and
Rheinl
(PB-230-xxAD1)
Model No. Output Tol. R&N Effi. Model No. Output Effi.
P□-120□-13□ 13.8V, 0~7.2A ±3~±8.5% 150mV 73% PB-230-12□ 14.4V, 0~16A 81.5%
P□-120□-27□ 27.6V, 0~4.3A ±1~±8.0% 200mV 79% PB-230-24□ 28.8V, 0~8A 85.5%
P□-120□-54□ 55.2V, 0~2.2A ±1~±7.5% 250mV 79% PB-230-48□ 57.6V, 0~4A 86.0%
□= Blank, AD1; Blank= XLR 4P, male type, AD1= Anderson connector

68
