Page 72 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Charger 108~360W Power Supply and Desktop Charger

ESP/ESC-120 ESP/ESC-240
ENP/ENC-120 / 180 / 240 / 360
Features for ESC/ESP Series Features for ENC/ENP Series
• AC input range selectable by switch • Universal AC input / Full range
• Fanless design, cooling by free air convection (ESP/ESC-120) • Energy efficiency Level VI (ENP only)
• Forced air cooling by built-in DC fan (ESP/ESC-240) • Comply with EISA 2007/DoE, NRCan, EU ErP and CoC Version 5 for ENP
• Protections: Short circuit / Overload / (EISA 2007/DoE, NRCan, EU ErP for ENP-360)
Over voltage / Over temperature • Built-in 3 stage charging curve, curve programmable option available
• 3 color LED loading indicator (ENC only)
• Fanless design, cooling by free air convection
• 2 years warranty
• Protections: Short circuit / Overload (ENP only) /
Over voltage / Over temperature
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)

Order No. ESP/ESC-120 ESP/ESC-240 ENP/ENC-120 ENP/ENC-180 ENP/ENC-240 ENP/ENC-360
AC input voltage range 88~132VAC / 176~264VAC selectable by switch 90~264VAC; 127 ~ 370VDC
AC inrush current (max.) Cold start, 40A at 230VAC Cold start, Cold start, Cold start, Cold start,
65A at 230VAC 70A at 230VAC 75A at 230VAC 60A at 230VAC
DC adjustment range 13.5V: 12~15V, 27V: 24~30V, 54V: 48~56V 12V: 11.5~15V, 24V: 23.5~30V, 48V: 47.5~58.8V / NA for ENC
Overload protection 105%~135% fold back current limiting, auto-recovery 110~125% constant current limiting, auto-recovery / NA for ENC
Over voltage protection 115%~135% constant voltage limiting, 110~130% shut down and latch off o/p voltage,
auto-recovery re-power on to recover
Over temp. protection Shut down o/p voltage, auto-recovery after temperature goes down
Withstand voltage I/P-O/P: 3kVAC, I/P-FG:1.5kVAC, O/P-FG: 0.5kVAC I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC
Working temperature -10~+60°C (refer to output derating curve) -30~+70°C (refer to output derating curve)
Safety standards CSA 62368-1, EAC TP TC 004 approved UL62368-1, EAC TP TC 004; BSMI CNS14336-1(ENC series only) approved
EMC standards EN55032 class B, EN61000-3-2,-3, EN61000-4-2,3,4 EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Dimension (LxWxH)(mm) 150x 140x 75 192x 178x 45.5
ESP/ESC-120 Series ENP-240 Series
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
ES□-120-13.5 13.5V, 0~8A ±2% 120mV 81% ENP-240-12 13.8V, 0~17.4A ±1% 150mV 91%
ES□-120-27 27V, 0~4A ±1% 150mV 83% ENP-240-24 27.6V, 0~8.7A ±1% 150mV 93.5%
ES□-120-54 54V, 0~2A ±1% 400mV 84%
□=P/C; P: Power supply, C: Charger ENP-240-48 55.2V, 0~4.4A ±1% 350mV 94%
ESP/ESC-240 Series ENP-360 Series

Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.
ESP-240-13.5 13.5V, 0~16A ±2% 120mV 81% ENP-360-12 13.8V, 0~26A ±1% 150mV 91%
ESP-240-27 27V, 0~8A ±1% 150mV 84% ENP-360-24 27.6V, 0~13A ±1% 150mV 93%
ESP-240-54 54V, 0~4A ±1% 400mV 85%
□=P/C; P: Power supply, C: Charger ENP-360-48 55.2V, 0~6.5A ±1% 350mV 94%
ENP-120 Series ENC-120/180 Series
Model No. Output Tol. R&N Effi. Model No. Output Effi. Model No. Output Effi.
ENP-120-12 13.8V, 0~8.7A ±1% 150mV 89.5% ENC-120-12 14.4V, 0~8A 89% ENC-180-12 14.4V, 0~12A 91%
ENP-120-24 27.6V, 0~4.3A ±1% 150mV 91% ENC-120-24 28.8V, 0~4A 90% ENC-180-24 28.8V, 0~6A 92%
ENP-120-48 55.2V, 0~2.2A ±1% 350mV 91.5% ENC-120-48 57.6V, 0~2A 90.5% ENC-180-48 57.6V, 0~3A 93%
ENP-180 Series ENC-240/360 Series
Model No. Output Tol. R&N Effi. Model No. Output Effi. Model No. Output Effi.
ENP-180-12 13.8V, 0~13A ±1% 150mV 91% ENC-240-12 14.4V, 0~16A 91% ENC-360-12 14.4V, 0~24A 91%
ENP-180-24 27.6V, 0~6.5A ±1% 150mV 93.5% ENC-240-24 28.8V, 0~8A 92% ENC-360-24 28.8V, 0~12A 93%
ENP-180-48 55.2V, 0~3.3A ±1% 350mV 94% ENC-240-48 57.6V, 0~4A 93% ENC-360-48 57.6V, 0~6A 94%
