Page 74 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Charger 300~1000W Battery Charger

PB-300 PB-360 PB-600 PB-1000

Features for PB-300/360 Features for PB-600/1000
• 3 stage charger for lead-acid batteries and Li-ion batteries • 2/3/8 stage smart charger for lead-acid batteries and Li-ion batteries,
• AC input range selectable by switch microprocessor controlled power management
• Passive PFC compliance to EN61000-3-2 class A (option) • CANBus potocol (optional for PB-1000)
• Protections: • Built-in active PFC function
Reverse polarity / Short circuit / Over voltage / Over temperature • Built-in battery rescue function
• 2 color LED loading indicator • Protections: Reverse polarity / Short circuit / Over voltage / Over temp.
• Fan ON/OFF control (PB-360 only) • Built-in temperature compensation function
• Cooling by free air convection for PB-300, • 2-bank charger (PB-1000)
Cooling by built-in DC fan for PB-360 • 3 color LED loading indicator
• 3 years warranty • Built-in remote ON-OFF control
• Fan ON/OFF control (PB-600)
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Order No. PB-300 PB-360 PB-600 PB-1000

AC input voltage range 90~132VAC / 180~264VAC selectable by switch 90~264VAC; 127~370VDC
AC inrush current (max.) Cold start, 60A at 230VAC Cold start, 50A at 230VAC
Over voltage protection 108%~125% rated output voltage 110%~125% rated output voltage
Withstand voltage I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC (I/P-FG: 1.5kVAC for PB-360)
Working temperature -10~+50°C -20~+60°C (refer to output derating curve)
IEC60335-2-29 CB approval by TUV TUV EN60335-1, EN60335-2-29
Safety standards (except for 48V), UL62368-1 approved, (except for 48V), EN62368-1 UL62368-1, TUV EN62368-1
(48V only), UL1012 approved,
EAC TP TC 004 EAC TP TC 004 approved, EAC TP TC 004
EMC standards EN55032 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3 (except for PB-300/360 non-PFC type), EAC TP TC 020
Case No. 801B 801A 805C 804B
Dimension (LxWxH)(mm) 253x 135x 48.5 230x 158x 67 300x 184x 70
PB-300 Series PB-600 Series
(except for 48V) (P type only)
Model No. Output (20 min.) / (Continuous at 25 C) Effi. Model No. Output Effi.
o
PB-300□-12 14.4V, 20.85A / 12.5A 85% PB-600-12 14.4V, 0~40.0A 86%
PB-300□-24 28.8V, 10.50A / 6.25A 86% PB-600-24 28.8V, 0~21.0A 87%
PB-300□-48 57.6V, 5.3A / 3.20A 88% PB-600-48 57.6V, 0~10.5A 89%
□ = P: with PFC; N: non PFC
PB-360 Series PB-1000 Series
(except for 48V) (P type only)
Model No. Output Effi. Model No. Output Effi.
PB-360□-12 14.4V, 24.3A 85% PB-1000-12 14.4V, 60.0A 85%
PB-360□-24 28.8V, 12.5A 86% PB-1000-24 28.8V, 34.7A 88%
PB-360□-48 57.6V, 6.25A 87%
□= P: with PFC; N: non PFC PB-1000-48 57.6V, 17.4A 89%
Built-in Charging Curves for PB-600 and PB-1000

2-Stage Charging Curve 3-Stage Charging Curve 8-Stage Charging Curve

Star t
V boos t
Charge Voltage
100%
Charge Current 10% Float
Stage 1 Stage 2
Constant Current Constant Voltage Battery Full
Color of LED Orange Green
