19" Rack Power 1600~24000W Distributed Power

Features
• Universal AC input / Full range(Withstand 300VAC surge for 5 seconds)
• Built-in active PFC function
• Built-in auxiliary power
• Protections: Short circuit / Overload / Over voltage / Over temperature
RCP-1600 • Forced air cooling by built-in DC fan
• High power density up to 25W/inch 3
• 1U low profile (41mm height)
• Output voltage programmable; Constant current level Icc programmable
• Active current sharing up to 5 units, 3 racks max. can be operated in
parallel (up to 15 units)
• Built-in remote ON/OFF control
• Built-in remote sense function
• AC OK and DC OK signal output
• Internal OR-ing FET, hot-swap operation
RHP-1U • Built-in PMBus serial communication, optional CANBus
• 5 years warranty

General Specification (Please refer to www.meanwell.com for detail spec.)
Order No. RCP-1600

AC input voltage range 90~264VAC, 127~370VDC
AC inrush current (max.) Cold start, 35A at 230VAC

Vo: -1%~+22.5% by potentiometer, or to 40%~125% of rated output voltage by 1~5VDC external control signal
DC adjustment range
Icc : to 20%~100% of rated output current by 1~5VDC external control signal
Overload protection (OLP) 105%~115% constant current limiting, shut down o/p voltage after 5 sec., re-power on to recover
Over voltage protection 130%~155% shut down o/p voltage, re-power on to recover

Withstand voltage I/P-O/P:3kVAC, I/P-FG:2kVAC, O/P-F/G: 1.5kVAC

Working temperature -30~+70°C (refer to output derating curve)
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004 approved

EN55032 class B (Radiation class A for RCP-1600), EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11,
EMC standards
EN61000-6-2 heavy industry level
Connection Positronic PCIM34W13M400A1
Dimension(LxWxH) 300x 85x 41mm (440x 365x 44mm for RHP-1U)

Case No. 250 (242A for RHP-1U)
Packing 1.87kg (RCP-1600, single unit); 5.5kg (RHP-1U, single empty rack)

Order Information
Rectifier ─ 1600W
Rectifier: RCP-1600- 12 - C Model No. Output Tol. R&N Effi.
: Standard model, PMBus protocol
C : Optional model, CANBus protocol RCP-1600-12 12V, 0~125A ±1% 150mV 88.5%
Output voltage(12V/24V/48V)
Rack Shelf: RHP-1U I -A RCP-1600-24 24V, 0~67A ±1% 200mV 91.0%
For RCP/RCB-1600
I : AC inlet(IEC320-C14) RCP-1600-48 48V, 0~33.5A ±1% 300mV 93.0%
T : Terminal block
