19" Rack Power 3200W Programmable & Intelligent Distributed Power NEW
DRP-3200
DHP-1UT
Features
• Universal AC Input/ Full Range • Built-in OR-ing MOSFET, support hot swap/plug
• Built-in active PFC function • Active current sharing, 1 19" 1U rack up to 12800W,
• High efficiency up to 94.5% 2 racks up to 25600W in parallel
2
• High power density 37W/in 3 • I C interface, support PMBus protocol (CANBus optional)
• Cooling by built-in DC fan • Protections: Short circuit / Overload / Over voltage / Over temperature
• PV (Programmable voltage)and • Optional conformal coating
PC (Programmable constant current) functions • 5 years warranty
Order Information
DRP-3200- 24 DHP-1U T - A
Communication protocol option Rack shelf for 3200W unit
Output voltage(24V/48V) T: Terminal block; I: AC inlet
Output wattage Profile of the system
Series name Series name
General Specification (Please refer to www.meanwell.com for detail spec.)
Order No. DRP-3200
AC input voltage range 90-264VAC; 127~370VDC
AC inrush current (max.) Cold start, 17A/230VAC
DC adjustment range 24V: 23.5-30V; 48V: 47.5-58.8V
Over voltage protection 24V: 31.5-37.5V; 48V: 63-75V
Withstand voltage I/P-O/P: 3KVAC; I/P-FG: 2KVAC; O/P-FG: 1.5KVAC (0.5KVAC for 24V)
Working temperature -30~+70°C (refer to output derating curve)
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004 approved
Compliance with EN55032 (CISPR32) Conduction Class B, Radiation Class A; EN61000-3-2, -3-3, EAC TP TC 020,
EMC standards
EN61000-4-2,3,4,5,6,8,11, EN61000-6-2
Connection Positronic PCIM34W13F400A1
Dimension(LxWxH)(mm) 325x 107x 41(1U)
Case No. 256 (257 for DHP-1U)
Packing 2.65kg; 4pcs / 11.6kg / 0.93CUFT
1600W DRP-3200
Model No. Output Efficiency Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also, they can offer
DRP-3200-24 24V, 0~133A 93.5% you technical support & RMA services. Please contact your
local distributors for more product information. You can also
contact us at info@meanwell.com for information of your local
DRP-3200-48 48V, 0~67A 94.5% distributors.
