Page 83 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Modular Series

NMS-240: 1-SLOT isolated dual output (240W max.) Parallel Connection Accessory

Item Code Output Vdc adj. Tol. R&N. Max.
FAP-009
C 5V, 0~36A 3~6V ±2% 100mV 180W (For NMS-240, 2 units)
FAP-010
E 12V, 0~20A 6~15V ±1% 150mV 240W (For NMS-240, 3 units)

H 24V, 0~10A 15~30V ±1% 150mV 240W NMS-240-P2/P3/P4/P5/P6
(to parallel NMS-240 in 2/3/4/5/6 modules)
K 48V, 0~5A 30~55V ±1% 250mV 240W Series Connection Accessory
FAS-005
(For 1-slot modules: NMS-240)
Blank Plate Accessory

Blank-NMS240
Introduction Video Assembly Video

Output Configuration Guide
Example:
NMP - - NMP 1K2- C E H H K K
SLOT 1 SLOT 2 SLOT 3 SLOT 4 SLOT 5 SLOT 6

650/1K2(650W/1200W) Parallel or SLOT6-o/p: 48V@5A
option code
SLOT5-o/p: 48V@5A
For NMP1K2 only
SLOT4-o/p: 24V@10A

SLOT3-o/p: 24V@10A
SLOT2-o/p: 12V@20A
SLOT1-o/p: 5V@36A

• 3Φ-3-wire/ 340~550Vac wide input range
• Vo: 100/ 200/ 300/ 400Vdc
• Digitalized Power Supply Design
• Built-in Active PFC
• Forced air cooling by built-in DC fans(RSTP series),
Conduction/Water cooling for industrial application(SHP series)
• Output voltage and constant current level programmable
• Active current sharing up to 30000W
• Built-in remote ON-OFF control / Remote sense / Auxiliary Power / Fault alarm signals
• Protections: Short circuit / Overload / Over voltage / Over temp. / Fan Fail
• 5 years warranty
