Page 78 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG
P. 78
19" Rack Power 1000~8000W Distributed Power
Features
• Universal AC input / Full range
• Built-in active PFC function
• Built-in auxiliary power
• Protections: Short circuit / Overload / Over voltage / Over temperature
RCP-1000 • Forced air cooling by built-in DC fan
• 1U low profile (41mm height)
• Active current sharing up to 3 units, 3 racks max. can be operated
in parallel (up to 8 units)
• Built-in remote ON/OFF control
• Built-in remote sense function
• AC OK and DC OK signal output
• Internal OR-ing diode, hot-swap operation
2
RCP-1U • Optional I C serial data bus; Built-in PMBus serial communication
• 5 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Order No. RCP-1000
AC input voltage range 90~264VAC, 127~370VDC
AC inrush current (max.) Cold start, 50A at 230VAC
DC adjustment range Vo: ±3% by potentiometer, or to 90%~110% of rated output voltage by external resistor
Overload protection (OLP) 105%~125% constant current limiting, auto-recovery
Over voltage protection 110%~135% shut down o/p voltage, re-power on to recover
Withstand voltage I/P-O/P:3kVAC, I/P-FG:2kVAC, O/P-F/G: 0.7kVDC
Working temperature -20~+60°C (refer to output derating curve)
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004 approved
EMC standards EN55032 class B (Radiation class A for RCP-1600), EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11,
EN61000-6-2 heavy industry level
Connection Positronic PCIB24W9M400A1
Dimension(LxWxH) 295x 127x 41mm (483.6x 350.8x 44mm for RCP-1U)
Case No. 952A (959A for RCP-1U)
Packing 1.93kg (RCP-1000, single unit); 4.4kg (RCP-1U, single empty rack)
Order Information Rectifier ─ 1000W
Rectifier: RCP-1000- 12 - C
2
C : with I C interface Model No. Output Tol. R&N Effi.
2
: without I C interface
Output voltage(12V/24V/48V) RCP-1000-12 12V, 0~60A ±1% 150mV 81.0%
Rack Shelf: RCP-1U I RCP-1000-24 24V, 0~40A ±1% 200mV 87.0%
I : AC inlet(IEC320-C14)
T : Terminal block RCP-1000-48 48V, 0~21A ±1% 300mV 89.0%
75
