Page 56 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Industrial Adaptor 5~15W Desktop & Wall-mounted Type

6W Green Adaptor 5W Green USB Adaptor
• Universal AC input / Full range • Pass LPS • Universal AC input / Full range
• No load power consumption < 0.075W • Fully enclosed plastic case • No load power consumption < 0.075W
• Energy efficiency Level VI • Approvals:
• Comply with EISA 2007/DoE and EU ErP UL/CUL/FCC for GS06U • Energy efficiency Level VI
• 2 pole US / European type plug TUV/CE for GS06E GS05U-USB • Comply with EISA 2007/DoE and EU ErP
• Class II power (without earth pin) • 2 years warranty 41.86x 32.76x 23.8 mm • Compact size
• Protections: Short circuit / Overload / • 2 pole US / European type plug
Over voltage
• Class II power (without earth pin)
• Protections: Short circuit / Overload
Over voltage / Over temp.
• Pass LPS
GS05E-USB • Fully enclosed plastic case
41.54x 30.5x 20 mm • 2 years warranty
AC input voltage range ...... 90~264VAC ; 127~370VDC
GS06U GS06E Overload protection ........... 105%~135% rated output power, hiccup mode,
66x 32x 42.5 mm 66x 32x 42.5 mm auto-recovery
Over voltage protection ..... 105%~200% rated output voltage, hiccup mode,
AC input voltage range ....90~264VAC ; 127~370VDC auto-recovery
AC inrush current(max.) .. Cold start, 50A at 230VAC Withstand voltage ............. I/P-O/P: 4242VDC, 1 minute
Overload protection ........ Hiccup mode, auto-recovery Working temperature ......... -20~+50°C (refer to output derating curve)
Over voltage protection ... Clamp by zener diode >120% Safety standards ............... U-Type: UL62368-1, CSA22.2, EAC TP TC 004 approved
Withstand voltage ........... I/P-O/P: 4242VDC, 1minute E-Type: TUV EN62368-1, EAC TP TC 004 approved
Working temperature ....... 0~+50°C (refer to output derating curve) EMC standards ................. FCC part15 class B(U Type); EN55032 class B(E Type)
Safety standards ......... UL62368-1, CSA 22.2, TUV EN62368-1, EAC TP TC 004 Standard DC plug .............. USB Type A
EMC standards ............... FCC part15 class B(U Type); EN55032 class B(E Type) Order No. Output Tol. R&N Effi.
Length of output cable ..... 120cm of 18AWG for 5~9V; 180cm of 24AWG for 12~48V GS05U-USB 5V, 0~1A ±4% 90mV 74.0%
Order No. Output Tol. R&N Effi. GS05E-USB 5V, 0~1A ±4% 80mV 74.5%
GS06□ -1P1J 5V, 0~1.00A ±5% 50mV 75.0%
GS06□ -11P1J 7.5V, 0~0.80A ±5% 80mV 80.5% 15W Green Adaptor
GS06□ -2P1J 9V, 0~0.66A ±5% 80mV 79.5% • Universal AC input / Full range • Protections:
GS06□ -3P1J 12V, 0~0.50A ±3% 100mV 79.5% • No load power consumption < 0.075W Short circuit / Overload / Over voltage
GS06□ -4P1J 15V, 0~0.40A ±3% 120mV 80.5% • Energy efficiency Level VI • Pass LPS
GS06□ -5P1J 18V, 0~0.33A ±3% 150mV 81.5% • Comply with EISA 2007/DoE and EU ErP • Fully enclosed plastic case
GS06□ -6P1J 24V, 0~0.25A ±2% 180mV 82.0% • 2 years warranty
GS06□ -8P1J 48V, 0~0.125A ±2% 200mV 85.0%
□ = U/E ; U: American 2P, E: European 2P
12W Green Adaptor
• Universal AC input / Full range • Pass LPS
• No load power consumption < 0.3W • Fully enclosed plastic case
• Energy efficiency Level V • Approvals: GS15B
GS15A
• Comply with EISA 2007 and EU ErP UL/CUL/BSMI/CB/FCC for GS12U 100x 58.5x 32.8 mm 100x 58.5x 32.8 mm
• 2 pole US / European type plug TUV/CB/CE for GS12E
• Class II power (without earth pin) • 2 years warranty
• Protections: Short circuit / Overload /
Over voltage / Over temp.
V V

GS15U GS15E
71x 34x 50 mm 71x 34x 50 mm
AC input voltage range ..... 90~264VAC ; 127~370VDC
AC inrush current(max.) .... Cold start, 50A at 230VAC
GS12U GS12E Overload protection ........... Hiccup mode, auto-recovery
65x 47x 26.5 mm 65x 47x 26.5 mm Over voltage protection ..... Clamp by zener diode > 120%
AC input voltage range .... 90~264VAC ; 127~370VDC Withstand voltage ............. I/P-O/P: 3kVAC, I/P-FG: 1.5kVAC, 1 minute
AC inrush current(max.) .. Cold start, 45A at 230VAC Working temperature ......... 0~+50°C (refer to output derating curve)
Overload protection ......... Hiccup mode, auto-recovery Safety standards ....UL62368-1, CSA 22.2, TUV EN62368-1, EAC TP TC 004 approved
Over voltage protection ... 115%~135% clamp by zener diode EMC standards ................. EN55032-B, EN61000-3-2,3,
Withstand voltage ........... I/P-O/P: 3kVAC, 1minute EN61000-4-2,3,4,5,6,11,FCC part 15 class B
Working temperature ....... 0~+50°C (refer to output derating curve) Length of output cable ....... 120cm of 18AWG for 5~15V; 180cm of 18AWG for 18~48V
Safety standards ...UL62368-1, CSA 22.2, BSMI CNS14336, TUV EN62368-1, EAC TP TC 004 Standard DC plug ..............P1J: 2.1øx5.5øx11mm / C+, tuning fork type
EMC standards ............... EN55032, EN61204-3, EN61000-3-2,3, (refer to page 59 for DC plug list)
EN61000-4-2,3,4,5,6,8,11, FCC part15 class B Order No. Output Tol. R&N Effi.
Order No. Output Tol. R&N Effi. GS15□ -1P1J 5.0V, 0~2.40A ±5% 50mV 80.0%
□
GS12 05-P1I 5V, 0~2.00A ±5% 75mV 76.0% GS15□ -11P1J 7.5V, 0~1.60A ±5% 80mV 82.5%
□
GS12 07-P1I 7.5V, 0~1.60A ±4% 90mV 78.5% GS15□ -2P1J 9.0V, 0~1.66A ±5% 80mV 85.0%
□
GS12 09-P1I 9V, 0~1.33A ±4% 90mV 78.5% GS15□ -3P1J 12V, 0~1.25A ±3% 80mV 85.0%
□
GS12 12-P1I 12V, 0~1.00A ±3% 120mV 78.5% GS15□ -4P1J 15V, 0~1.00A ±3% 100mV 85.0%
18V, 0~0.83A
±3%
85.0%
120mV
□
GS15□ -5P1J
GS12 15-P1I 15V, 0~0.80A ±3% 150mV 80.0% GS15□ -6P1J 24V, 0~0.625A ±2% 150mV 85.5%
□
GS12 18-P1I 18V, 0~0.67A ±3% 180mV 80.0% GS15□ -8P1J 48V, 0~0.31A ±2% 240mV 87.0%
□
GS12 24-P1I 24V, 0~0.50A ±3% 200mV 80.5% □ = A/B/E/U ; A:IEC320-C14, B: IEC320-C8
□ = U/E ; U: American 2P, E: European 2P E: European 2P, U: American 2P
